VA160302N small slewing ring bearing thin-wall slewing bearings
| Slewing bearing No. | VA160302N | |
| Weight | [kg] | 14 |
| Outer diameter (O.D.) | [mm] | 384 |
| Inner diameter (I.D.) | [mm] | 238 |
| Bore diameter of outer ring | [mm] | |
| Outside diameter of inner ring | [mm] | 302.3 |
| Overall height | [mm] | 32 |
| External bolt circle diameter | [mm] | 343 |
| Number of bolt hles | 20 | |
| Internal bolt circle diameter | [mm] | 262 |
| Number of bolt hles | 20 | |
| Bolt hole diameter | [mm] | M12 |
| Bolt size | [mm] | M12 |
| Height of outer ring | [mm] | 30 |
| Height of inner ring | [mm] | 30 |
| Gear P.C.D. | [mm] | 376 |
| Module | [mm] | 4 |
| Number of Teeth | 94 | |
| tooth width | [mm] | 30 |
| JINB slewing bearing | SEL160302G1 | |
If you have any inquiry, please contact me:
Email: m@jinbearings.com
Tel:+86-21-6152 0863
